Symbol Meanings
HI LO Transmission power high (HI) 25W or low (Lo) 1W.
Indicates an incoming DSC call or blank to notify you of any unread call
log messages.
TX Indicate that the radio is Transmitting
RX Indicate that the radio is receiving a radio signal.
M Indicate the current channel has been saved in memory.
Indicate the current work at Memory mode (Channel is selected at saved
channels).
DU TRI Indicate Watch state.
ALT An weather alert signal are received, In US and Canada
88 Channel selected.
I Indicates channel bank for VHF radio operations and regulations.
PSCAN Indicate the current work in priority-scan mode.
SCAN Indicate the current work at the scan mode.
DSC DSC capability is available.
Battery Low indicates vessel battery voltage is low.
X Channel is temporarily deleted from the all scan operation.
ATIS Enable for use In European in inland waterway other wise blank
Dot Matrix Display indicates special conditions or radio functions.
2.4 LCD symbol and meanings
