29
6.1 Menu function description
The radio’s setup functions are accessed through the Menu mode. Menu
mode selections are as follows.
6. SETUP MENU
Item Description
Buddy list
Selects the BUDDY List Entry routine to enter Names and MMSI’s for
frequently called DSC stations. Up to 20 names could be stored.
Backlight set the backlight level, total 8 level be available.
Contrast Selects display contrast setting: 1-8 levels.
GPS/Time
Set the Position info if no GPS attached and define the display POS and
Time format, Offset and COG/SOG display settings.
Radio setup
There are 4 items that user can customize – CH Name, Ring Tone Volume,
Beep Volume and Internal Speaker on/off.
DSC Setup
There are 5 functions that allow user to alter – User MMSI entry, Group
MMSI entry, Individual Reply, DSC enable , and POS reply
Reset Recall ex-factory setting
6.2 Set-Up Menu Navigation
To access the Menu Mode:
Press and hold MENU/DSC key, Text area displays the Set-Up Menu list.
To exit the Menu mode or sub –mode:
Press the 16/9 or CANCEL key or else select the EXIT option from the menu.
Rotate the CH knob to select the Item within the Set-Up Menu list
To confirm a selected item for adjustment, push the CH knob.
When the desired setting is done, press the CH knob to enter the setting, and
move back to the Main Menu list.
Set Up operation is exited by turning the unit off. All changes are saved in
EEPROM (exception Manual Enter GPS Data)
During Set-Up operation, TX and RX are availability.
6.3 Buddy List
The Buddy List can store up to 20 entries with Name and MMSI. User can
add, edit or delete the record from the list under this submenu.
