Command Protocol Reference Guide
A - 53
Description
This parameter selects the type of ring tone to be generated for the telephony
interface. If ring tones are enabled, the selected tone is played whenever there
is an incoming ring signal on the telephony interface.
The parameter values correspond to the following tones.
• 1: normal ring
• 2: low trill
• 3: low double trill
• 4: medium trill
• 5: medium double trill
• 6: high trill
• 7: high double trill
• 8: highest trill
• 9: highest double trill
• 10: beeble
• 11: triplet
• 12: low trill precedence
• 13: ring splash
• 14: silent ring
phone_ring_tone_en
Enable Ring Tones For Telephony Interface
System Limits Minimum: 1, Maximum: 14
Default 1
Event Source No
Argument Argument value
Argument Argument value
Channel Type Virtual Channel
Value Type Boolean
Read/Write Mode Read/Write
Phys Chans Analog Telephony Input
