A status message is only generated if there is a state change. This helps keep data traffic to a
minimum.
This command is a boolean command. See
Section 6.1 for more information on this type of command.
This command is saved to non-volatile memory only as part of a preset. The state of this command will
be restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
T01LIEN1
Enable automatic logic input status messages.
T01LIEN1
T01LIEN0
Disable automatic logic input status messages.
T01LIEN0
T01LIEN2
Toggle automatic logic input status messages.
T01LIENx, where x is 0 or 1 depending
on the current setting of LIEN.
T01LIEN?
Query automatic logic input status messages.
T01LIENx, where x is 0 or 1 depending
on the current setting of LIEN.
8.47. LIG -- Configure Logic Input Pins Into a Group
This conmmand configures which logic input pins are in a group. Logic groups allow events to happen
when certain combinations of inputs are present on the logic pins. For example, if a logic group was
defined that consisted of three logic input pins (pin 1, pin 2, and pin 3), then a total of eight
combinations (2
3
) are possible, and a command or macro can be assigned to each combination. This
feature is particularly useful in room-combining applications. It can also be used to make controls based
on rotary switches that output binary, BCD, or Gray codes.
Commands can be assigned to the configurations of a logic group via the
LIN command.
This command is saved to global non-volatile memory and is not part of a preset. Its value is saved
each time it is changed. It will retain its value after power-down. Since this command writes to non-
volatile memory, there will be a delay before an acknowledgment is returned.
Example Description Status Message
T01LIG2,000011110000000000000000
Configure
Logic Group
2 to contain
logic input
pins 5-8.
T01LIG2,000011110000000000000000
