This command is saved to non-volatile memory only as part of a preset. The state of this command will
be restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
T01LOEN1
Enable automatic logic output status
messages.
T01LOEN1
T01LOEN0
Disable automatic logic output status
messages.
T01LOEN0
T01LOEN2
Toggle automatic logic output status
messages.
T01LOENx, where x is 0 or 1 depending
on the current setting of LOEN.
T01LOEN?
Query automatic logic output status messages.
T01LOENx, where x is 0 or 1 depending
on the current setting of LOEN.
8.56. LOK -- Delete One or All Logic Output Pin Commands
This command "kills" or deletes all commands for a given logic output pin. In other words, the
commands associated with
LOA and LOD will be deleted for the specified logic output. A wildcard
character can also be specified for the logic output pin, in which case the commands for all logic output
pins will be deleted.
Using this command is more efficient than deleting one command or pin at a time since this command
deletes them all at once and requires fewer writes to non-volatile memory.
This command is saved to global non-volatile memory and is not part of a preset. Its value is saved
each time it is changed. It will retain its value after power-down. Since this command writes to non-
volatile memory, there will be a delay before an acknowledgment is returned.
Example Description Status Message
T01LOK5
Delete all the commands associated with logic output pin 5. This one
command is equivalent to executing the commands ' T01LOA5,' and '
T01LOD5,' except that this command is more efficient.
T01LOK5
T01LOK*
Delete all the commands associated with all logic output pins. This one
command is equivalent to executing the commands ' T01LOA1,' and '
T01LOD1,' for each logic output, except that this command is much
more efficient.
T01LOK*
8.57. LOM -- Mask Logic Output Pins
This command is used to mask (i.e., disable) logic output pins. The mask consists of 20 fields (one for
each logic output) that can each be set to 0 or 1. If the mask bit for a given logic output is set to 1,
then the logic output pin works normally. If the mask bit for a given logic output is set to 0, then the
logic output is disabled. When a a logic output is disabled, it is "frozen" in whatever state it is in when it
is disabled. The output pin's state will not change when the condition that drives it (via
LOA and LOD)
