T# Time (sec) Description Error Code Solution
18
22
25
20
24
HUD LED. This test measures the amount of electrical current
consumed by the red LED in the Head-Up Display (HUD),
when activated.
HUD Vibrator. This test measures the amount of electrical
current consumed by the vibrator motor in the Head-Up
Display (HUD), when activated.
Metabolic O
2
Solenoid #2. This test measures the amount of
electrical current consumed by the second metabolic solenoid
valve, when activated. It does not check that the solenoid
actually opens and closes (veried during the Positive Pressure
Loop Test, t49).
Buddy-Light LED. This test measures the amount of electrical
current consumed by the red LED in the battery (Buddy-Light),
when activated.
Metabolic O2 Solenoid #1. This test measures the amount of
electrical current consumed by the rst metabolic solenoid
valve, when activated. It does not check that the solenoid
actually opens and closes (veried during the Positive Pressure
Loop Test, t49). The test is only applicable for E-modules with
dual metabolic O2 solenoid.
4.5
4.5
9
4.5
9
11=Current
too low
12=Current
too high
11=Current
too low
12=Current
too high
11=Current too low
12=Current too high
87=Voltage too low
88= Voltage
too high
11=Current
too low
12=Current
too high
11=Current too low
12=Current too high
87=Voltage too low
88= Voltage
too high
1) Standard Response; 2) If test failure persists, or if no faint “click” sound
from the main electronics module can be heard at the start of this test, contact
an authorized Poseidon Service Center for repair.
1) Standard Response; 2) If test failure persists, or the HUD does not vibrate
during this test, contact an authorized Poseidon Service Center for repair.
1) Standard Response; 2) If test failure persists, or if no faint “click” sound
from the main electronics module can be heard at the start of this test, contact
an authorized Poseidon Service Center for repair.
1) Standard Response; 2) If test failure persists, or the Battery LED does not
turn on during this test, contact an authorized Poseidon Service Center for
repair.
1) Standard Response; 2) If test failure persists, or the HUD LED does not
turn on during this test, contact an authorized Poseidon Service Center for
repair.
19 HUD LED. This test measures the amount of electrical current
consumed by the green LED in the Head-Up Display (HUD),
when activated.
4.5 11=Current
too low
12=Current
too high
1) Standard Response; 2) If test failure persists, or the Battery LED does not
turn on during this test, contact an authorized Poseidon Service Center for
repair.
23 Intro Test.
Mouthpiece Closed-Circuit Position. This test requires that the
mouthpiece is set in Closed-Circuit (CC) position in order to
pass.
120 0=Timeout 1) Ensure that the moutpiece is fully in the CC position (sometimes requires
rm pressing on the mouthpiece lever); 2) Ensure that the HUD is properly
positioned on the top of the mouthpiece, and that the exhaust cover is
holding it tightly in place; 3) If test failure persists, contact an authorized
Poseidon Service Center for repair.
