© 2006 Schneider Electric All Rights Reserved
63230-500-224A1 PowerLogic
®
Series 800 Power Meter
6/2006 Appendix A—Specifications
EN–63
ENGLISH
Control Power
AC Control Power
Operating Range 115–415 ±10% Vac
Burden 15 VA maximum with options
Frequency 45–67 Hz, 350–450 Hz
Ride Through 45 ms at 120 Vac
DC Control Power
Operating Range 125–250 ±20% Vdc
Burden 10 W maximum with options
Ride Through 45 ms at 125 Vdc
Environment
Operating Temperature
Meter -25°C to +70°C
➃
Display -10°C to +50°C
Operating Environment
Relative Humidity 5–95% (non-condensing)
Maximum Elevation 3,000 m
Pollution Degree 2
IP Rating
Meter 30
Display
NOTE: The display must be mounted on
a flat surface.
52
Regulatory/Standards Compliance
Emissions
Radiated FCC part 15 Class A, EN55011
Conducted FCC part 15 Class A, EN55011
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Table A – 1: Specifications
Specifications based on 50/60 Hz nominal systems.
➀Full scale = 10A. Add 0.006%(°C - 25) to the upper limit error for temperatures
below 25°C.
➁Full scale = 600V. Add 0.001%(°C) to the upper limit error for temperatures
above 50°C.
➂Full scale = 120V x 10A. Add 0.006%(°C) to the upper limit error for temperatures
below 25°C.
➃Requires 5°C derating when using the display and control power above 305 Vac.
➄Derate load current 0.56 mA per °C above 25°C.
