PowerLogic
®
Series 800 Power Meter 63230-500-224A1
Appendix A—Specifications 6/2006
EN–64
ENGLISH
Immunity IEC 61000-6
ESD IEC 61000-4-2 Level 3
Radiated IEC 61000-4-3 Level 3
EFT IEC 61000-4-4 Level 3
Surges IEC 61000-4-5 Level 3
Conducted IEC 61000-4-6 Level 3
Magnetic Field IEC 61000-4-8 Level 3
Voltage Dips IEC 61000-4-11 Level
Standards (listed)
USA UL 61010 / IEC 61010
Europe CE per EN 61010
Table A – 1: Specifications
Specifications based on 50/60 Hz nominal systems.
➀Full scale = 10A. Add 0.006%(°C - 25) to the upper limit error for temperatures
below 25°C.
➁Full scale = 600V. Add 0.001%(°C) to the upper limit error for temperatures
above 50°C.
➂Full scale = 120V x 10A. Add 0.006%(°C) to the upper limit error for temperatures
below 25°C.
➃Requires 5°C derating when using the display and control power above 305 Vac.
➄Derate load current 0.56 mA per °C above 25°C.
