Chapter 8 Installation and Spare Circuit
99
TA
TB
TC
Relay output
MO1
MCM
Signal output
JP6
Analog output
0 to 10V / 0 to
20mA
AO1
GND
1
2
3
V
I
JP2
JP3
DI1
DI2
DI3
DI4
DI5
DI1 input terminals
DI2 input terminals
DI3 input terminals
DI4 input terminals
DI5 input terminals
COM
PLC
+24V
1
2
3
JP1
+24V
COM
PLC
JP4
Control circuit
M
3
P
RB
Braking resistor
(optional)
PI130
inverter
Main circuit
R
S
T
U
V
W
R
S
T
485
communication
port
1
2
3
V
I
VR
1K
2W
+10V
AI1
GND
AI2
V
I
