Powtran pi130 series User Manual

Chapter 5 Function parameter
31
No.
Code
Parameter name
Setting range
Factory
default
Change
Reference
page
73.
F3.07
Waiting time of
stop braking
0.0 to 50.0s
0.0 s
☆
61
74.
F3.08
Stop DC braking
current
0.0 to 150.0%
0.0%
☆
61
75.
F3.09
Stop DC braking
time
0.0 to 50.0s
0.0 s
☆
61
5-1-6.F4 Group - V/F control
No.
Code
Parameter name
Setting range
Factory
default
Change
Reference
page
76.
F4.00
V/F curve setting
0: linear V/F curve
1: multi-point V/F
curve
2: square V/F curve
3:1.75th power V/F
curve
4:1.25th power V/F
curve
0
★
62
77.
F4.01
Torque boost
0.0%: automatic torque
boost
0.1% to 30.0%
0.0%
☆
62
78.
F4.02
Torque boost cut-
off
0.0% to 50.0% (relative
to rated frequency of
motor)
20.0%
★
62
79.
F4.03
V/F frequency
point 1
0.00Hz to F4.05
0.00Hz
★
63
80.
F4.04
V/F voltage point
1
0.0% to 100.0%
0.0%
★
63
81.
F4.05
V/F frequency
point 2
F4.03 to F4.07
0.00Hz
★
63
82.
F4.06
V/F voltage point
2
0.0% to 100.0%
0.0%
★
63
83.
F4.07
V/F frequency
point 3
F4.05 to b0.04 (rated
motor frequency)
0.00Hz
★
63
84.
F4.08
V/F voltage point
3
0.0% to 100.0%
0.0%
★
63
