Powtran pi130 series User Manual

Chapter 5 Function parameter
27
No.
Code
Parameter name
Setting range
Factory
default
Change
Reference
page
34.
F0.13
AVR function
selection
0: Invalid
1: full valid
2: only invalid during
deceleration
1
☆
52
5-1-3.F1 Group - Input terminals
No.
Code
Parameter name
Setting range
Factory
default
Change
Reference
page
35.
F1.00
DI1 terminal
function selection
0: No function
1: Forward run
2: Reverse run
3: Three-wire
operation control
4: Forward Jog
5: Reverse Jog
6: Frequency setting
increment (UP)
7: Frequency setting
decrement (DOWN)
8: Free stop
9: Fault reset
10: External fault
input
11: Frequency change
settings clear
12: Multi-speed
terminal 1
13: Multi-speed
terminal 2
14: Multi-speed
terminal 3
15: Multi-speed
terminal 4
16: Ac/deceleration
time selection
17: Control command
switch terminal
18: Ac/deceleration
prohibited
19: PID control pause
20: Wobbulate pause
(stops at the current
frequency)
21: Wobbulate reset
1
★
53
36.
F1.01
DI2 terminal
function selection
2
★
53
37.
F1.02
DI3 terminal
function selection
8
★
53
38.
F1.03
DI4 terminal
function selection
9
★
53
39.
F1.04
DI5 terminal
function selection
4
★
53
40.
F1.05
Reserved
