Powtran pi130 series - F7 Group - Auxiliary Function Group

Chapter 5 Function parameter
67
Code
Parameter name
Setting range
Factory
default
Change
F6.04 to
F6.07
Reserved
5-2-9.F7 Group - Auxiliary function group
Code
Parameter name
Setting range
Factory
default
Change
F7.00
Jog running frequency
0.00 to F0.08 (maximum
output frequency)
5.00Hz
☆
F7.01
Jog running acceleration time
0.1 to 3600.0s
Depends on
models
☆
F7.02
Jog running deceleration time
0.1 to 3600.0s
Depends on
models
☆
Defined the inverter's setting frequency and ac/deceleration time when jogging Jog
running start mode: direct start-up, and jog running stop mode: deceleration stop (F3.05
= 0) .
Jog running acceleration time refers to the time required that the inverter accelerates
from 0Hz to maximum output frequency (F0.08) ;
Jog running deceleration time refers to the time required that the inverter decelerates
from maximum output frequency (F0.08) to 0Hz.
F7.03
Acceleration time 2
0.1 to 3600.0s
Depends on
models
☆
F7.04
Deceleration time 2
0.1 to 3600.0s
Depends on
models
☆
PI130 provides two sets of acceleration and deceleration time. Their meanings are the
same, please refer to the instructions on F0.05 and F0.06.
Use multi-function digital input terminal DI to set, switch between ac/deceleration 1
and ac/deceleration time 2. For the detailed method, please refer to the instructions on
function codes F1.00 to F1.05.
F7.05
Jump frequency
0.00 to F0.08 (maximum
output frequency)
0.00Hz
☆
F7.06
Jump frequency range
0.00 to F0.08 (maximum
output frequency)
0.00Hz
☆
