Powtran pi130 series User Manual

Chapter 5 Function parameter
46
5-2.Function parameter description
5-2-1.dO Group - Monitoring function group
d0 parameters group is used to monitor the inverter running status information,user
can view those information through the panel to facilitate on-site commissioning, also
read parameters group value via communication for host computer monitoring.
Parameter function code
Parameter name
Smallest unit
d0.00
Running frequency
0.01Hz
Actual output frequency of inverter running
d0.01
Set frequency
0.01Hz
Inverter current actual setting frequency
d0.02
DC bus voltage
1V
Inverter bus voltage value
d0.03
Inverter output voltage
1V
Actual output voltage when the inverter running
d0.04
Inverter output current
0.1A
Actual output current when the inverter running
d0.05
Inverter output power
0.1kW
Actual output power when the inverter running
d0.06
Inverter output torque
1%
Actual output torque percentage when the inverter running
d0.07
Input terminal status
-
DI input terminal status is currently displayed, when it is converted into binary data,
one bit corresponds to one DI terminal input signal, 1 indicates that the input terminal
is high level signal, 0 indicates that the input terminal is low-level signal.
Bit0
Bit1
Bit2
Bit3
Bit4
DI1
DI2
DI3
DI4
DI5
Bit5
Bit6
Bit7
Bit8
Bit9
Reserved
Reserved
Reserved
Reserved
Reserved
d0.08
Output terminal status
-
