Powtran pi130 series User Manual

Chapter 5 Function parameter
43
No.
Code
Parameter name
Setting range
Factory
default
Change
Reference
page
192.
E3.16
VDO valid state
Units digit: VDO1
0: positive logic
1: negative logic
Tens digit: VDO2
(same as units digit)
Hundreds digit:
VDO3 (same as units
digit)
Thousands digit:
VDO4 (same as units
digit)
Ten thousands digit:
VDO5 (same as units
digit)
00000
☆
86
193.
E3.17
VDO1 delay time
0.0 to 3600.0s
0.0 s
☆
86
194.
E3.18
VDO2 delay time
0.0 to 3600.0s
0.0 s
☆
86
195.
E3.19
VDO3 delay time
0.0 to 3600.0s
0.0 s
☆
86
196.
E3.20
VDO4 delay time
0.0 to 3600.0s
0.0 s
☆
86
197.
E3.21
VDO5 delay time
0.0 to 3600.0s
0.0 s
☆
86
5-1-18.b0 Group - Motor parameters
No.
Code
Parameter name
Setting range
Factory
default
Change
Reference
page
198.
b0.00
Inverter type
0: G-type machine; 1:
Reserved
0
★
87
199.
b0.01
Rated motor
power
0.4 to 900.0kW
Depends
on models
★
87
200.
b0.02
Rated motor
voltage
0 to 460V
Depends
on models
★
87
201.
b0.03
Rated motor
current
0.1 to 2000.0A
Depends
on models
★
87
202.
b0.04
Rated motor
frequency
0.01Hz to F0.08
(maximum output
frequency)
50.00Hz
★
87
203.
b0.05
Rated motor
speed
0 to 36000rpm
Depends
on models
★
87
204.
b0.06
Motor stator
resistance
0.001 to 65.535Ω
Depends
on models
☆
87
205.
b0.07
Motor rotor
resistance
0.001 to 65.535Ω
Depends
on models
☆
87
