Chapter 5 Function parameter
47
Parameter function code
Parameter name
Smallest unit
Displays current output terminal state value. When it is converted into binary data, one
bit corresponds to one output terminal input signal, 1 indicates that the input terminal is
high level signal, 0 indicates that the output terminal is low-level signal.
Bit0
Bit1
Bit2
Bit3
Bit4
MO1
Reserved
Reserved
R0
Reserved
d0.09
Analog AI1 value
0.01V
Analog AI1 input voltage value
d0.10
Analog AI2 value
0.01V
Analog AI2 input voltage value
d0.11
Panel potentiometer voltage
0.01V
Panel potentiometer input voltage value
d0.12
Motor actual speed
1rpm
Display motor actual running speed
d0.13
PID setting value
0.1%
Setting value percentage under PID adjustment mode
d0.14
PID feedback value
0.1%
Feedback value percentage under PID adjustment mode
d0.15
Current stage of multi-speed
-
Display current stage of multi-speed
d0.16
Reserved
d0.17
Inverter module temperature
0.1
Display the inverter module temperature
d0.18
Software version
-
Display DSP software version number
d0.19
Cumulative running time of this unit
1h
Display the total run time of inverter
d0.20
Torque setting value
0.1%
Observe the set command torque under the speed control mode or the torque control
mode
5-2-2.F0 Group - Basic function group
