Powtran pi130 series User Manual

Chapter 5 Function parameter
42
No.
Code
Parameter name
Setting range
Factory
default
Change
Reference
page
176.
E3.00
VDI1 function
selection
0 to 25
0
★
83
177.
E3.01
VDI2 function
selection
0 to 25
0
★
83
178.
E3.02
VDI3 function
selection
0 to 25
0
★
83
179.
E3.03
VDI4 function
selection
0 to 25
0
★
84
180.
E3.04
VDI5 function
selection
0 to 25
0
★
84
181.
E3.05
VDI active mode
Units digit: Virtual
VDI1
Tens digit: Virtual
VDI2
Hundreds digit:
Virtual VDI3
Thousands digit:
Virtual VDI4
Ten thousands digit:
Virtual VDI5
00000
★
84
182.
E3.06
VDI status setting
Units digit: Virtual
VDI1
Tens digit: Virtual
VDI2
Hundreds digit:
Virtual VDI3
Thousands digit:
Virtual VDI4
Ten thousands digit:
Virtual VDI5
11111
★
84
183.
E3.07
AI1_DI function
0 to 25
0
★
85
184.
E3.08
AI2_DI function
selection
0 to 25
0
★
85
185.
E3.09
Panel
potentiometer_DI
setting
0 to 25
0
★
85
186.
E3.10
AI_DI mode
Units digit: AI1
0: high level active
1: low level active
Tens digit: AI2 (same
as units digit)
Hundreds digit: Panel
potentiometer (same
as units digit)
000
★
85
187.
E3.11
VDO1 output
function
0 to 10
0
☆
86
188.
E3.12
VDO2 output
function
0 to 10
0
☆
86
189.
E3.13
VDO3 output
function
0 to 10
0
☆
86
190.
E3.14
VDO4 output
function
0 to 10
0
☆
86
191.
E3.15
VDO5 output
function
0 to 10
0
☆
86
