Chapter 5 Function parameter
33
No.
Code
Parameters
Setting range
Factory
default
Change
Reference
page
95.
F6.01
Running status
display
parameters
selection
0 to 0xFFFF
BIT0: Running
frequency
BIT1: Set frequency
BIT2: Bus voltage
BIT3: Output voltage
BIT4: Output current
BIT5: Running speed
BIT6: Output power
BIT7: Output torque
BIT8: PID setting
value
BIT9: PID feedback
value
BIT10: Input terminal
status
BIT11: Output
terminal status
BIT12: Analog AI1
value
BIT13: Analog AI2
value
BIT14: Current stage
of multi-speed
BIT15: Torque set
value.
03FF
☆
66
96.
F6.02
Stop status
display
parameters
selection
1 to 0x3FF
BIT0: Set frequency
BIT1: Bus voltage
BIT2: Input terminal
status
BIT3: Output terminal
status
BIT4: PID setting
value
BIT5: PID feedback
value
BIT6: Analog AI1
value
BIT7: Analog AI2
value
BIT8: Current stage of
multi-speed
BIT9: Torque set
0FF
☆
66
