Powtran pi130 series User Manual

Chapter 5 Function parameter
79
Code
Parameter name
Setting range
Factory default
Change
E1.03
Multi-speed 3
-100.0% to 100.0%
0.0%
☆
E1.04
Multi-speed 4
-100.0% to 100.0%
0.0%
☆
E1.05
Multi-speed 5
-100.0% to 100.0%
0.0%
☆
E1.06
Multi-speed 6
-100.0% to 100.0%
0.0%
☆
E1.07
Multi-speed 7
-100.0% to 100.0%
0.0%
☆
E1.08
Multi-speed 8
-100.0% to 100.0%
0.0%
☆
E1.09
Multi-speed 9
-100.0% to 100.0%
0.0%
☆
E1.10
Multi-speed 10
-100.0% to 100.0%
0.0%
☆
E1.11
Multi-speed 11
-100.0% to 100.0%
0.0%
☆
E1.12
Multi-speed 12
-100.0% to 100.0%
0.0%
☆
E1.13
Multi-speed 13
-100.0% to 100.0%
0.0%
☆
E1.14
Multi-speed 14
-100.0% to 100.0%
0.0%
☆
E1.15
Multi-speed 15
-100.0% to 100.0%
0.0%
☆
The start-stop channel selection is determined by the function code F0.02 under the
multi-speed mode, multi-speed process is controlled by the combination of terminal 1,
terminal 2, terminal 3 and terminal 4. The relationship of stage and multi-speed is
followed as:
The relationship of multi-speed and multi-speed terminal is followed as:
Multi-
speed
terminal
4
Multi-
speed
terminal
3
Multi-
speed
terminal
2
Multi-
speed
terminal
1
Command setting
Parameters
OFF
OFF
OFF
OFF
Multi-speed
command 0
E1.00
OFF
OFF
OFF
ON
Multi-speed
command 1
E1.01
OFF
OFF
ON
OFF
Multi-speed
command 2
E1.02
OFF
OFF
ON
ON
Multi-speed
command 3
E1.03
OFF
ON
OFF
OFF
Multi-speed
command 4
E1.04
OFF
ON
OFF
ON
Multi-speed
command 5
E1.05
OFF
ON
ON
OFF
Multi-speed
command 6
E1.06
OFF
ON
ON
ON
Multi-speed
E1.07
