■ 8 Data transfer to peripheral devices
52
8 Data transfer to peripheral
devices
For data-transfers to peripheral devices, the balance is equipped with
an RS232/V24-interface.
Before the data-transfer, the RS232 interface must be matched with
the one in the peripheral device in the balance's configuration menu
see Chapter 5.7 “Interface-functions” and the Precisa BUS must be
switshed off see Chapter 5.12 “Precisa BUS”.
• Handshake
The handshake is set to “NO” (none) in the works. It can be set to
software handshake XON/XOFF, or to hardware handshake.
• Baud rate
Possible baud rates: 300, 600, 1200, 2400, 4800, 9600, or
19200 baud.
• Parity
Possible parity: 7 even 1 stop, 7 odd 1 stop, 7 No 2 stop, 8 No 1 stop
*8 even 1 stop or *8 odd 1 stop.
(* setting not available for firmware Nxx)
• Display
Pos.012345678910
7-even-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA PB SP -
7-odd-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA PB SP -
7-no-2 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA 1.SP 2.SP -
8-no-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA 8.DA SP -
8-even-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA 8.DA PB SP
8-odd-1 SB 1.DA 2.DA 3.DA 4.DA 5.DA 6.DA 7.DA 8.DA PB SP
SB: Start bit PB: Parity bit
DA: Data bit SP: Stop bit
S D7 D6 D5 D4 D3 D2 D1 D0 U U U
