3. Tension an align the Drive Belt to specification, see "Drive Belt Tension and Align-
ment Adjustment" on page 57. DO NOT switch the power ON at this step, the Drive
Belt operation will be verified later in the procedure.
4. Tension the Running Belt to specification and verify tracking, see "Running Belt Ten-
sion and Tracking Adjustment" on page 62.
5. Do a manual workout and verify the drive belt alignment and operation. Make sure
that the belt remains centered and that there are no unusual noises or squeaking
sounds.
6. Reinstall the left & right Landing Trim covers, see "Covers and Panels Replacement"
on page 80 and the hood cover, see "Covers and Panels Replacement" on page 80.
7. Verify Operation (see "Operation Verification" on page 23) and return to service.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 143
6 Replacement Procedures
Drive Roller Replacement
