DIAGNOSTIC TEST TEST DESCRIPTION
INCLINE TEST
menu: MACHINE TEST > INCLINE TEST
Test parameters:
• A/D
1
- lift motor incline position potentiometer A/D number.
• SEC - UP/DWN command response delay between the
UPCA
2
and LPCA
3
.
• Glitches - Momentary failures in the A/D potentiometer out-
put. If there are more than 50 Glitches, the lift motor should be
replaced.
.
STOP KEY TEST
menu: MACHINE TEST > STOP KEY TEST
(P10, P30 consoles only)
Verifies the Stop Key and E-Stop function
Test sequence steps:
1. StopKey test - Press the Stop Key
2. Lanyard ESTOP
4
test- Pull the lanyard to trip the emer-
gency stop function.
3. Exit test - Press the Stop button to reset and exit test.
(1) Only included on products that have the ASL feature.
(2) Not included on the EFX600 series or TRM600 series products.
Club Settings Menu (5651565)
Service Access Code: 5651565 (see "Service Menu Access Codes" on page 27)
Used to customize the equipment user interface localization, Workouts configuration, and
maintenance default settings.
menu: Club Settings (51765761) > DIAGS - CLUB SETTINGS
1
analog to digital converter
2
Upper PCA board
3
Lower Printed Circuit Assembly board; also refered to as the Lower PCA or simply as the
lower board. On treadmills, it is the console to base function interface and the motor con-
troller unit (MCU). On self-powered units, it is the lower PCA console to base function inter-
face.
4
Emergency Stop: Safety clip and lanyard attached to the stop switch to immediately turn
off power bringing the treadmill to a stop.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 38
4 Standard Service Menus
LED Console Standard Service Menus
