DIAGNOSTIC TEST TEST DESCRIPTION
KEYBOARD TEST
An illuminated LED map of the function keys will be shown.
Press each individual key and verify that the corresponding
LED extinguishes. Press and hold BACK to exit the test.
PVS
1
KEY TEST Not used, OEM test.
HEART RATE
Tests the unfiltered and filtered pulse heart rate. Grasp the
grips to test the handheld heart rate. Use a Polar heart rate
simulator to test the wireless heart rate. Press the BACK but-
ton to exit this test.
ACTIVE STATUS
LIGHT
(1)(2)
The current ASL
2
status light state (blue. pulsing blue, yellow,
& pulsing yellow).
AS LIGHT
BRIGHTNESS
(1)(2)
Sets the ASL light brightness level and ON/OFF state: HIGH.
MED, LOW, and ON/OFF.
MC
3
LIGHT
(2)
Machines with ASL functionality
Indicates the current fault status of the MC:
l Green - OK
l Yellow: Fault condition
Hold the Quick Start hardkey to reset.
Machines without ASL functionality
(2)
Used as an ON/OFF light:
BELT SPEED TEST
menu: MACHINE TEST > BELT SPEED TEST
Tests belt operating condition in 0.1 speed increments
Test parameters:
• AMPS IN: Treadmill input Current.
• VOLTS IN: Treadmill input Voltage
• VBUSS: Treadmill internal buss Voltage
• AMPS MTR: Current supplied to the drive motor.
AUTO STOP TEST
menu: MACHINE TEST > AUTO STOP TEST
Test parameters:
• Status - Exerciser detected on or off the running belt.
• Step Count - Average # of footplants. Footplant averaging
delay reset with each speed change.
.
1
Personal Viewing System display.
2
Active Status Light: Service and maintenance status light.
3
Motor controller, motor controller unit, or motor controller module: used on treadmills, con-
tains the LPCA and motor controller functionality.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 37
