Hood Cover Replacement
Hood Cover Replacement
ID Description
Hood Cover
Removal Instructions
1.
Remove the four #3 Phillips hood cover screw fasteners. Retain part(s) and/or
fastener(s) for installation.
2.
Grasp the lower edge of the hood cover and pull outwards while lifting to release
the tab clip fasteners. Then carefully lift and slide the hood towards the back of the
treadmill through the targa uprights to remove.
Installation Instructions
1.
Position the hood cover over the front motor compartment by sliding the hood
front through the targa uprights from the back towards the front. Grasp the bottom
edge of the hood cover and pull outwards while pressing down on the cover top at the
front and back to snap the tab clip fasteners into place.
2.
Secure the hood cover using the four #3 Phillips screw fasteners and fully tighten.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 82
6 Replacement Procedures
Covers and Panels Replacement
