lengths)
(1) or equivalent synthetic Teflon based grease (Mobil 1, NLGI 2 Teflon Synthetic
Grease).
Specification Summary
Fastener Torque Specification
System component fastener torque specification:
System Component Specification
RF
1
coax connector 2.4 in-lbs (0.271 Nm)
Display mounting fasteners 180 in-lbs (20 Nm
Set screws 300 in-lbs (34 Nm)
Plastite screw fasteners 20 in-lbs (2.3 Nm)
Flathead screws 25 in-lbs (2.8 Nm)
Deck front fasteners 27-33 in-lbs (3.1-3.7 Nm)
Deck rear fasteners 50-55 in-lbs (5.6-(6.2 Nm)
Drive Motor fasteners 204 in-lbs (17 ft-lbs, 23 N-m)
Calibration Specification
System calibration specification:
System Component Specification
Lift Motor Jackscrew Calibration gap 1 1/8 in - 1 3/16 in (2.8 cm - 3.0 cm)
Forbo Drive Belt Tension New Belt
(1)
100-120 lbs (45-54 kgs)
Forbo Drive Belt Tension Used Belt
(1)
80-90 lbs (36-41 kgs)
Forbo - Running Belt: tension gauge dial reading
(percent %)
3.55 (0.55%)
(2)
1
Radio Frequency: Identifies electromagnetic signals with frequency spectrum between the
3 kHz (3,000 hertz) to 300 GHz (300 billion hertz) range.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 11
