4.
Repeat the same removal procedure to remove both the left or right trim end
cap covers.
Installation Instructions
Repeat procedure for both the left and right covers.
5. Reinstall the end cap cover onto the end of the frame rail and press to lock cover tabs
in place.
6. Secure using two #3 Phillips screw fasteners. One screw on the top and one screw on
the back. Fully tighten both screws.
7.
Repeat the same installation procedure to install both the left and right trim
end cap covers.
1.
Remove the back cover , see "Covers and Panels Replacement" on
page 80.
2. Remove the console, refer to the treadmill assembly guide on precor.com.
3.
Remove the four #3 Phillips screw fasteners and remove the front cover .
Retain part(s) and/or fastener(s) for installation.
8. Reinstall the left and right trim landing covers, see "Covers and Panels Replacement"
on page 80.
9. Reinstall the hood cover, see "Hood Cover Replacement" on page 82.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 89
6 Replacement Procedures
Covers and Panels Replacement
