Label Stock 9
3. Remove any shipping tape from your label stock roll to ensure
that it can unroll freely, making certain that no adhesive portion
is exposed. It is important to note that any exposed adhesive
surface can attach itself the inner workings of the print
mechanism and cause a media jam.
4. Place your roll of label stock on the Roll Arm and push it inward
until it touches the Roll Stop.
5. Flip up the Roll Guide and slide it inward until it touches the
label stock. The Roll Guide will automatically pull back slightly
to the correct position. There should be approximately a 1mm
gap between the roll guide and the roll.
Important Note: Be aware that some label stock may have a core that
is slightly too large for the roll or the labels may have wrapped unevenly
causing some to stick out beyond the edge of the core.
Both of these issues can cause feeding problems.
DO NOT PINCH
Roll Guide
Roll Arm
Roll Stop
To Next Page
