Section 5 Service Procedures
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the dryer(s) before servicing.
• Close gas shut-off valve to gas dryer(s) before servicing.
• Never start the dryer(s) with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the dryer is properly grounded.
W001R1
WARNING
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
(c.) Remove screw holding exhaust duct
to dryer cabinet and pull duct out of
cabinet. Refer to Figure 58.
(d.) Remove two screws from each rear
cabinet top hold-down bracket. Refer
to Figure 61.
(e.) Remove screw holding terminal block
access plate to rear of dryer cabinet
and remove plate.
(f.) Remove wire harness clips.
(g.) Remove locators and screws.
(15) Remove two cabinet top hold-down screws.
Refer to Figure 26.
NOTE: When servicing, cabinet top may be raised
and hinged on the rear hold-down brackets or
supported against wall behind dryer.
(16) Carefully withdraw wire harness through
hole in cabinet top and lift the top off the
rear hold-down brackets.
NOTE: Retainer clips hold the wire harness to the
side panel of the dryer. Remove these before
attempting to withdraw wire harness.
(17) Set cabinet top aside.
(18) Remove two rivets holding gusset and coin
meter bracket to back panel. Refer to
Figure 62.
(19) Remove two screws holding hold-down
brackets to back panel. Refer to Figure 60.
(20) Remove 13 screws attaching back panel to
dryer. Refer to Figure 62. Remove back
panel.
Metered Models:
a. Side Panels:
(1) Remove two screws from bottom edge of
access panel. Refer to Figure 7. Remove
access panel.
(2) Remove two screws holding bottom tabs on
front panel to dryer cabinet front. Refer to
Figure 37. Swing bottom of front panel
away from dryer far enough to disengage
hold-down clips and locators from cabinet
top.
(3) Disconnect wires from door switch.
NOTE: Refer to appropriate wiring diagram when
rewiring control panel components.
(4) Remove front panel.
(5) Disengage belt from motor and idler
pulleys. Refer to Figure 48.
NOTE: When reinstalling belt, be sure belt is
properly installed on motor and idler pulleys and is
on the correct side of the idler lever. Refer to
Figure 47. Belt must be positioned around center
section of cylinder approximately three inches
ahead of rear rib on cylinder with the ribbed
surface of the belt against the cylinder. Refer to
Figure 57. After installing belt, manually rotate
cylinder counterclockwise to check that belt is
properly aligned.
(6) Remove four screws holding front
bulkhead to dryer. Refer to Figure 26.
NOTE: Air duct can remain attached to front
bulkhead.
NOTE: When reassembling the front bulkhead to
the cabinet, hold glides in position with finger tips
on the edges of glides. Once bulkhead is in place,
inspect the glide position with a mirror to ensure the
glides are aligned with the cylinder, making sure the
tabs are visible. Refer to Figure 54.
