Module

/ slot

Index Name Module

name

Identifi‐

cation

(hex)

Type Data

flow *

Description

4 Tempera‐

ture error

Temperature

too high

5 Hose rup‐

ture

Metering hose

damaged

6 -

7 -

8 -

9 -

10 -

11 -

12 -

13 Bus error Bus error

reported by the

module

14 System

error

System compo‐

nents faulty -

see display

15 Module

error

Error in module

handling

16 -

17 -

18 -

19 -

20 -

21 -

22 -

23 -

24 -

25 -

26 -

27 -

28 -

29 -

30 -

31 -

2 Warn‐

ings

u16 Bit Name Function

0 Minimum Metering liquid

level is low

Supplementary operating instructions for PROFIBUS

Table of Contents2
Supplementary Operating Instructions for Canopen4
About this Pump4
Control Elements5
Electrical Installation5
Emergency Mode7
Troubleshooting7
Accessories8
Appendix9
Communication Profile Area 0X1000-0X1Fff9
Manufacturer Specific Profile Area 0X2000-0X5Fff9
Device Profile Area 0X6000-0X9Fff16
Alarm Action Area for Measurement Devices (404 )19
Emergency19
Explanations of Objects21
Changing the Canopen Node Address (Node ID)24
Transfer Rate (Baud Rate)24
Calibration, Explanations24
Firmware Update25
Data Storage25
Directives / Standards Complied with25
Supplementary Operating Instructions for Modbus RTU26
About this Modbus Pump26
Control Elements27
Electrical Installation27
Setting Options for the Pump Control Elements30
Modbus RTU" Implementation31
Modbus RTU" Message Structure32
Device Monitoring33
Emergency Mode34
Functional Faults34
Accessories35
Modbus RTU for Prominent Pumps Register35
Device Identification" Register36
Modbus" Register36
Production Data Pump Assembly-Specific" Register37
Production Data Modbus Module-Specific" Register38
Current Operating Parameters" Register39
Target Operating Parameter" Register42
Advanced Configuration" Register43
Accessories 1" Register46
Accessories 3" Register46
Debug Data" Register47
Supplementary Operating Instructions for PROFIBUS48
Requirements48
Setting the Pump48
General48
Switching PROFIBUS ® to Active / Inactive48
Setting the Slave Address49
Special Features in the Active PROFIBUS ® Mode50
General50
Displays50
Leds on the PROFIBUS ® Module50
Installation51
Operation53
General53
GSD File53
DULCO Flex Control Dfxa, Dfxa Data Objects53
Supplementary Operating Instructions for PROFINET61
Requirements61
Setting the Pump61
General61
Activating / Deactivating PROFINET61
Configuring PROFINET62
Special Features in Active PROFINET ® Mode63
General63
Displays63
Leds on the PROFINET ® Module64
Installation64
Operation65
General65
GSDML File65
DULCO Flex Control Dfxa, Dfxa Data Objects66
PLC Error and Pump Behaviour72
