ProMinent DULCO flex Control Supplementary Operating Instructions

Module
/ slot
Index Name Module
name
Identifi‐
cation
(hex)
Type Data
flow *
Description
5 1 Max.
flow
rate
Max.
flow
rate
40.83 f32 R Maximum dosing rate in litres / hour
6 1 Batch
volume
Batch C0,83,8
8
f32 W Batch dosing volume
2 Batch
time
u16 Time during which the batch is to be
metered
3 Batch
start
u8 If the value changes from 1 to 0,
batch metering is triggered in batch
mode. (Batch metering can also be
triggered via the contact input.)
4 Batch
memory
u8 If “Batch Memory” is activated and a
new batch is triggered while batch
metering is in progress, then the
remaining volume to be metered will
increase by the volume of the new
batch. If “Batch Memory” is not acti‐
vated, the remaining volume is
deleted and the new batch metering
process is started.
5 Remaini
ng
volume
f32 R The remaining volume to be metered
in batch mode
7 1 Contact
volume
Con‐
tact
80.84 f32 W Volume metered per contact
2 Contact
memory
u8 - see “Batch Memory”
8 1 Con‐
centra‐
tion rate
Con‐
centra‐
tion
C0,83,8
3
f32 W Concentration setting setpoint (only
in
‘Concentration’ operating mode)
2 Actual
concen‐
tration
f32 R Actual value of the concentration set‐
ting (only in
‘Concentration’ oper‐
ating mode)
* R = read, W = write
Tab. 35: Error / Warning
Module
/ slot
Index Name Module
name
Identifi‐
cation
(hex)
Type Data
flow *
Description
9 1 Error Error /
Warning
40.85 u32 R Bit Name Function
0 Minimum Feed chemical
level is too low
1
2 Analogue
< 4mA
Analogue cur‐
rent is less than
4 mA
3 Analogue
> 23mA
Analogue cur‐
rent is greater
than 23 mA
Supplementary operating instructions for PROFIBUS
®
57
