ProSoft Technology MVI56E-MCMXT User Manual

Reference MVI56E-MCM ♦ ControlLogix Platform
User Manual Modbus Communication Module
Page 132 of 209 ProSoft Technology, Inc.
Block Request from Processor to Module
Word Offset
Description
Length
0
5001 to 5006 or 5101 to 5106
1
1
Command index (MCM.CONFIG.PORTXMASTERCMD [command
index value])
1
2
Command index (MCM.CONFIG.PORTXMASTERCMD [command
index value])
1
3
Command index (MCM.CONFIG.PORTXMASTERCMD [command
index value])
1
4
Command index (MCM.CONFIG.PORTXMASTERCMD [command
index value])
1
5
Command index (MCM.CONFIG.PORTXMASTERCMD [command
index value])
1
6
Command index (MCM.CONFIG.PORTXMASTERCMD [command
index value])
1
7 to 247
Spare
241
Blocks in the range of 5001 to 5006 are used for Modbus Port 1, and blocks in
the range of 5101 to 5106 are used for Modbus Port 2. The last digit in the block
code defines the number of commands to process in the block. For example, a
block code of 5003 contains 3 command indexes for Modbus Port 1. The
Command index parameters in the block have a range of 0 to 99 and correspond
to the Master command list entries.
The module responds to a Command Control block with a block containing the
number of commands added to the command queue for the port. The following
table describes the format for this block.
Block Response from Module to Processor
Word Offset
Description
Length
0
Reserved
1
1
Write Block ID
1
2
Number of commands added to command queue
1
3 to 248
Spare
246
249
5000 to 5006 or 5100 to 5106
1
