MVI56E-MCM ♦ ControlLogix Platform Reference
Modbus Communication Module User Manual
ProSoft Technology, Inc. Page 173 of 209
6.8.6 Force Single Coil (Function Code 05)
Query
This Function Code forces a single coil (Modbus 0x range) either ON or OFF.
Any coil that exists within the controller can be forced to either state (ON or
OFF). However, because the controller is actively scanning, unless the coil is
disabled, the controller can also alter the state of the coil. Coils are numbered
from zero (coil 0001 = zero, coil 0002 = one, and so on). The data value 65,280
(FF00 HEX) sets the coil ON and the value zero turns it OFF; all other values are
illegal and does not affect that coil.
The use of Slave address 00 (Broadcast Mode) forces all attached Slaves to
modify the desired coil.
Note: Functions 5, 6, 15, and 16 are the only messages that are recognized as valid for broadcast.
The example below is a request to Slave number 11 to turn ON coil 0173.
Note: This is the structure of the message being sent out to the Modbus network. The byte values
below are in hexadecimal display.
Response
The normal response to the Command Request is to re-transmit the message as
received after the coil state has been altered.
The forcing of a coil via Modbus function 5 is accomplished regardless of
whether the addressed coil is disabled or not (In ProSoft products, the coil is only
affected if the necessary ladder logic is implemented).
Note: The Modbus protocol does not include standard functions for testing or changing the
DISABLE state of discrete inputs or outputs. Where applicable, this may be accomplished via
device specific Program commands (In ProSoft products, this is only accomplished through ladder
logic programming).
Coils that are reprogrammed in the controller logic program are not automatically
cleared upon power up. Thus, if such a coil is set ON by function Code 5 and
(even months later), an output is connected to that coil, the output is "hot".
