ProSoft Technology MVI56E-MCMXT User Manual

Configuration as a Modbus Master MVI56E-MCM ♦ ControlLogix Platform
User Manual Modbus Communication Module
Page 42 of 209 ProSoft Technology, Inc.
Label
Description
DevAddress
Specifies the Modbus Slave address for the registers associated with
that command. This is the offset address for the Modbus Slave device.
With Modbus, to read an address of 40001, what will actually be
transmitted out port is Function Code 03 (one byte) with an address of
00 00 (two bytes). This means that to read an address of 40501, use
Func 3 with a DevAddress of 500.
This applies to Modbus addresses 10001 to 47999.
Below is a definition that will help with your DevAddress configuration:
Function Codes 1, 5, or 15
 DevAddress = Modbus address in device - 0001
Example: Modbus address 0001 = DevAddress 0
 Modbus address 1378 = DevAddress 1377
Function Code 2
 DevAddress = Modbus address in device - 10001
Example: Modbus address 10001 = DevAddress 0
 Modbus address 10345 = DevAddress 344
Function Codes 3, 6, or 16
 DevAddress = Modbus address in device - 40001
Example: Modbus address 40001 = DevAddress 0
 Modbus address 40591 = DevAddress 590
Function Code 4
 DevAddress = Modbus address in device - 30001
Example: Modbus address 30001 = DevAddress 0
 Modbus address 34290 = DevAddress 4289
2.2.3 Other Modbus Addressing Schemes
While the above information will handle most devices, some device
manufacturers show their Modbus addressing differently.
The two most common schemes are six-digit addressing (400101, 301000,
etc…) and some devices show their addressing already as an offset address (the
address that actually goes out on the Modbus communication line). This is an
example.
Actual Values (Input Registers) Addresses: 0200 to 0E1F
STATUS
0200
Switch Input Status
0201
LED Status Flags
0202
LED Attribute Flags
0203
Output Relay Status Flags
If your device manufacturer gives you addressing like this, "Input Registers" then
you will use Function Code 4, and then place the address shown in the
DevAddress field. Also, most manufacturers that show this type of addressing will
list the address in hex, as is the case with the device shown above. So for this
example device, use Func = 4 (Input Registers) with a DevAddress of 512
decimal (200h) to read the "Switch Input Status" value.
