ProSoft Technology MVI56E-MCMXT User Manual

Reference MVI56E-MCM ♦ ControlLogix Platform
User Manual Modbus Communication Module
Page 158 of 209 ProSoft Technology, Inc.
6.5.5 Port 2 Commands
Register
Content
Description
12,670 to 12,677
Command #1
This set of registers contains the parameters for
the first command in the Master command list.
Refer to Master Command Configuration (page
39).
12,678 to 12,685
Command #2
Command #2 data set
-
-
-
15,626 to 15,629
Command #325
Command #325 data set
6.5.6 Misc. Status
Register
Content
Description
15,270
Program Scan Count
This value is incremented each time a complete
program cycle occurs in the module.
15,271 to 15,272
Product Code
These two registers contain the product code of
"MCM".
15,273 to 15,274
Product Version
These two registers contain the product version
for the current running software.
15,275 to 15,276
Operating System
These two registers contain the month and year
values for the program operating system.
15,277 to 15,278
Run Number
These two registers contain the run number value
for the currently running software.
15,279
Port 1 Command List
Requests
This field contains the number of requests made
from this port to Slave devices on the network.
15,280
Port 1 Command List
Response
This field contains the number of Slave response
messages received on the port.
15,281
Port 1 Command List
Errors
This field contains the number of command errors
processed on the port. These errors could be due
to a bad response or command.
15,282
Port 1 Requests
This field contains the total number of messages
sent from the port.
15,283
Port 1 Responses
This field contains the total number of messages
received on the port.
15,284
Port 1 Errors Sent
This field contains the total number of message
errors sent from the port.
15,285
Port 1 Errors Received
This field contains the total number of message
errors received on the port.
15,286
Port 2 Command List
Requests
This field contains the number of requests made
from this port to Slave devices on the network.
15,287
Port 2 Command List
Response
This field contains the number of Slave response
messages received on the port.
15,288
Port 2 Command List
Errors
This field contains the number of command errors
processed on the port. These errors could be due
to a bad response or command.
15,289
Port 2 Requests
This field contains the total number of messages
sent out the port.
