ProSoft Technology MVI56E-MCMXT User Manual

MVI56E-MCM ♦ ControlLogix Platform Reference
Modbus Communication Module User Manual
ProSoft Technology, Inc. Page 159 of 209
Register
Content
Description
15,290
Port 2 Responses
This field contains the total number of messages
received on the port.
15,291
Port 2 Errors Sent
This field contains the total number of message
errors sent out the port.
15,292
Port 2 Errors Received
This field contains the total number of message
errors received on the port.
15,293
Read Block Count
This field contains the total number of read blocks
transferred from the module to the processor.
15,294
Write Block Count
This field contains the total number of write blocks
transferred from the module to the processor.
15,295
Parse Block Count
This field contains the total number of blocks
successfully parsed that were received from the
processor.
15,296
Command Event Block
Count
This field contains the total number of command
event blocks received from the processor.
15,297
Command Block Count
This field contains the total number of command
blocks received from the processor.
15,298
Error Block Count
This field contains the total number of block errors
recognized by the module.
15,299
Port 1 Current Error
For a Slave Port, this field contains the value of
the current error code returned. For a Master Port,
this field contains the index of the currently
executing command.
15,300
Port 1 Last Error
For a Slave Port, this field contains the value of
the last error code returned. For a Master Port,
this field contains the index of the command with
the error.
15,301
Port 2 Current Error
For a Slave Port, this field contains the value of
the current error code returned. For a Master Port,
this field contains the index of the currently
executing command.
15,302
Port 2 Last Error
For a Slave Port, this field contains the value of
the last error code returned. For a Master Port,
this field contains the index of the command with
an error.
15,303 to 15,350
Spare
15,351
Port 1
InterCharacterDelay
0 to 65535 milliseconds time between characters
to signal end of message
15,352
Port 1 Fcn 99 Offset
Internal DB offset to Function 99 counter.
15,353 to 15,360
Spare
15,360
Spare
15,361
Port 2
InterCharacterDelay
0 to 65535 milliseconds time between characters
to signal end of message
15,362
Port 2 Fcn 99 Offset
Internal DB offset to Function 99 counter.
15,363 to 15,399
Spare
