MVI56E-MCM ♦ ControlLogix Platform Diagnostics and Troubleshooting
Modbus Communication Module User Manual
ProSoft Technology, Inc. Page 83 of 209
5.4 Setting Up ProSoft Configuration Builder
ProSoft Configuration Builder (PCB) provides a convenient way to configure,
diagnose, and troubleshoot your MVI56E-MCM module.
5.4.1 Installing ProSoft Configuration Builder
The ProSoft Configuration Builder (PCB) software is used to configure the
module. You can find the latest version of the ProSoft Configuration Builder
(PCB) on our web site: http://www.prosoft-technology.com. The installation
filename contains the PCB version number. For example,
PCB_4.1.0.4.0206.EXE.
If you are installing PCB from the ProSoft website:
1 Open a browser window and navigate to
http://www.prosoft-technology.com/pcb.
2 Click the download link for ProSoft Configuration Builder, and save the file to
your Windows desktop.
3 After the download completes, double-click the file to install. If you are using
Windows 7, right-click on the PCB installation file and click RUN AS
ADMINISTRATOR. Follow the instructions that appear on the screen.
4 If you want to find additional software specific to your MVI56E-MCM, enter
the model number into the website search box and press the Enter key.
