MBTCP.CONTROL.EventSequenceCommand
This tag array contains the values needed to build one Modbus TCP/IP
command, have it sent to a specific client on the module, and control the
processing of the returned response block.
Tag Name
Range
Description
MBTCP.CONTROL.EventSequence
Command.Trigger
0 or 1
Toggle to send Event Sequence Command.
0 = Disable, 1 = Enable
MBTCP.CONTROL.EventSequence
Command.ClientID
0 to 19
Client ID associated with the command to be
executed
MBTCP.CONTROL.EventSequence
Command.ServerIPaddress
xxx.xxx.xxx
.xxx
IP address of target Modbus server
MBTCP.CONTROL.EventSequence
Command.ServicePort
502 or
2000
Service port of target Modbus server
MBTCP.CONTROL.EventSequence
Command.SlaveAddress
1 to 255
Slave address of target Modbus TCP/IP to
serial device, if applicable
MBTCP.CONTROL.EventSequence
Command.InternalDBaddress
0 to 9999
(word-level)
or
0 to 65535
(bit-level)
Specifies the module’s internal database
register to be associated with the command.
Allowable range is:
0 to 9999 for Modbus Function Codes 3, 4, 6, or
16
0 to 65535 for Modbus Function Codes 1, 2, 5,
or 15.
MBTCP.CONTROL.EventSequence
Command.RegisterCount
1 to 125
(words)
or
1 to 800
(coils)
Specifies the number of registers or digital
points to be associated with the command.
Modbus Function Codes 5 and 6 ignore this field
as they only apply to a single data point.
MBTCP.CONTROL.EventSequence
Command.SwapCode
0,1,2,3
Specifies if the data received from the Modbus
server is to be ordered differently than received
from the server device.
This parameter is helpful when dealing with
floating-point or other multi-register values, as
there is no standard method of storage of these
data types in server devices.
MBTCP.CONTROL.EventSequence
Command.ModbusFC
1,2,3,4,5,6,
15,16
Specifies the Modbus function to be executed
by the command.
MBTCP.CONTROL.EventSequence
Command.DeviceModbusAddress
0 to 9999
Specifies the register or digital point address
offset within the Modbus server device. The
MBTCP client reads or writes from/to this
address within the server.
MBTCP.CONTROL.EventSequence
Command.SequenceNumber
Event Sequence Command Number
MBTCP.CONTROL.EventSequence
Command.StatusReturned
Event Sequence Command Returned
0 = Fail
1 = Success
-1 = Client disabled /inactive
MBTCP.CONTROL.EventSequence
Command.CmdInQue
Number of Event Sequence commands in
queue
