ProSoft Technology MVI69E-MBTCP User Manual

Using Controller Tags MVI69E-MBTCP ♦ CompactLogix Platform
User Manual Modbus TCP/IP Enhanced Communication Module
Page 84 of 150 ProSoft Technology, Inc.
June 28, 2017
MBTCP.CONTROL.Time
This array allows the processor to get or set module time.
Tag Name
Range
Description
MBTCP.CONTROL.Time.SetTime
0 or 1
Sends the PLC time to the module
0 = Disable, 1 = Enable
MBTCP.CONTROL.Time.GetTime
0 or 1
Retrieves the time from the module to PLC
0 = Disable, 1 = Enable
MBTCP.CONTROL.Time.Year
0 to 9999
Four digit year value. Example: 2014
MBTCP.CONTROL.Time.Month
1 to 12
Month
MBTCP.CONTROL.Time.Day
1 to 31
Day
MBTCP.CONTROL.Time.Hour
0 to 23
Hour
MBTCP.CONTROL.Time.Minute
0 to 59
Minute
MBTCP.CONTROL.Time.Second
0 to 59
Second
MBTCP.CONTROL.Time.Milliseconds
0 to 999
Millisecond
MBTCP.CONTROL.Time.Error
0 or -1
0 = OK
-1 = Error present
MBTCP.CONTROL.ClientServerControl
This array allows the control and retrieval of driver command active bits.
Tag Name
Range
Description
MBTCP.CONTROL.ClientServerControl.
Trigger
0 or 1
Toggle client/server control
0 = Disable, 1 = Enable
MBTCP.CONTROL.ClientServerControl.
ActiveServer
0 or 1
Server active state:
0 = Disable, 1 = Enable
MBTCP.CONTROL.ClientServerControl.
ActiveClient_0to15
Client 0 to 15 bit map for active status of clients
MBTCP.CONTROL.ClientServerControl.
ActiveClient_16to19
Client 16 to 19 bit map for active status of
clients
MBTCP.CONTROL.ClientServerControl.
ActiveClientCmd[x]
0 or 1
Client 0 to 19 command active bits. One word
for each client. Each bit is a command.
0 = Disable, 1 = Enable
MBTCP.CONTROL.ClientServerControl.
GetStatus
0 or 1
Toggle request for status
0 = Disable, 1 = Enable
MBTCP.CONTROL.ClientServerControl.
ServerStatus
0 or 1
Server active state
0 = Disabled, 1 = Enabled
MBTCP.CONTROL.ClientServerControl.
Client_0to15Status
Client 0 to 15 bit map for active status of clients
MBTCP.CONTROL.ClientServerControl.
Client_16to19Status
Client 16 to 19 bit map for active status of
clients
MBTCP.CONTROL.ClientServerControl.
ClientCmdStatus[x]
0 or 1
Clients 0 to 19 command active bits. One word
for each client. Each bit is a command.
0 = Disabled, 1 = Enabled
