SEQUENTIAL programming mode
This step-by-step programming procedure allows you full control of each setting and finer professional adjustments.
If the control panel is programmed using this procedure, obstacle detection function
is automatically disabled.
IMPORTANT:
Please check first that motors force (default setting level is 7 in a 1 to 10 range) is suitable to the
leaves’ weight.
In case of very light or very heavy gates please adjust and settings in FORCE menu
accordingly before carry-out any programming procedure: the leave shouldn't stop if a light force is opposed.
- If possible is better to program the control unit when motors are cold (not after repeated use)
- The gate must have opening and closing ground stops for a correct SEQUENTIAL programming procedure.
You can program the control panel with the sequential procedure using button on the control panel
or using a remote control previously saved.
1 Use buttons to move inside the menu, till the display shows:
2 Press button to confirm. The display shows:
3 Press the remote control (or button on the control panel).
• Leaf 1 starts opening.
4 When Leaf 1 is about to 90% of the opening path, press again the remote control
(or button on the control panel).
• Leaf one decelerates and continues opening.
5 Once Leaf 1 has reached the fully open position, wait 4 - 5 seconds and then press
again the remote control (or button ).
The working parameters for Leaf 1 have been set. The display now shows:
6 Repeat steps 3, 4, 5 of this procedure to set working times for Leaf 2 too.
7 Now working times, deceleration times and the level of sensibility for obstacle detection
have been automatically set.
If and settings are changed once programming is completed, you need to re-start AUTOMATIC
programming procedure again.
