3.1 MOTORS wiring
M1 motor 1 → first opening and last closing leaf.
M2 motor 2 → last opening and first closing leaf.
Wire motor 1 M1 to terminals 12 - 13 - 14 on JP7 terminal block.
Wire motor 2 M2 to terminals 15 - 16 - 17 on JP8 terminal block.
In case of single leaf gate, please wire the motor to 12 - 13 - 14 terminals on terminal block JP7.
Please see the following wiring scheme for your automation model as the Open/Close connections may vary:
AUTOMATION MODEL
