Q80A_8_2017 22
PROTECO S.r.l.
Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. +39 0173 210111 - Fax +39 0173 210199 info@proteco.net - www.proteco.net
SINGLE LEAF Function
Enable this setting in case of a single-leaf swing gate.
1 Use buttons to move inside the menu, till the display shows:
2 Press button to confirm.
3 Use buttons to select:
SINGLE LEAF Function OFF
SINGLE LEAF Function ON
4 Press button to go back to the top level menus,
then press button again till the display shows:
or wait the timeout (20 seconds) to exit.
SEPARATE PUSH-BUTTONS Function
This allows to use to different push-buttons/controls for opening and closing.
To use this function, you need to wire:
- opening push-button/control to START terminals
- closing push-button/control to PEDESTRIAN START terminals
1 Use buttons to move inside the menu, till the display shows:
2 Press button to confirm.
3 Use buttons to select:
SEPARATE PUSH-BUTTONS Function OFF
SEPARATE PUSH-BUTTONS Function ON
4 Press button to go back to the top level menus,
then press button again till the display shows:
or wait the timeout (20 seconds) to exit.
MOTORS TEST Function
If this function is enabled, the control panel performs a quick start-up test
with the motors to make sure that they are in operation.
1 Use buttons to move inside the menu, till the display shows:
2 Press button to confirm.
3 Use buttons to select:
MOTORS TEST Function OFF
MOTORS TEST Function ON
4 Press button to go back to the top level menus,
then press button again till the display shows:
or wait the timeout (20 seconds) to exit.
