2.2.1 External connection view
Figure 2-1 External connection view
1. Trolley 7. Main unit
2. Hooks 8. Patient system
3. Gas supply pipeline (Oxygen and AIR) 9. Humidifier
4. Mains power plug 10. SpO
2
finger clip
5. User screen 11. Sampling port of CO
2
6. Mechanical arm
