Prunus Boaray 5000C - Ventilator Front View; Ventilator Rear View

12
2.2.4 Ventilator front view
Figure 2-4 Ventilator front view
1. Holding arms 6. Nebulizer interface
2. Expiratory valve heating silk-screen 7. Inspiratory silk-screen
3. Expiratory port 8. Inspiratory port
4. Expiratory silk-screen 9. Oxygen sensor installation position
5. Expiratory valve unlock silk-screen
2.2.5 Ventilator rear view
VGA/OU T
CO
2
SpO
2
No Obstruct
1
5
4
6
7
89
2
3
Figure 2-5 Ventilator rear view
