B.6 CO
2
module specification (Optional)
Parameter Specification
Measuring mode Mainstream
Operation temperature 0-40℃/ 32-104 ℉
Storage and transportation
temperature
-40-75℃/ -40-167 ℉
Operating humidity
< 40 hPa H2O (non-condensing)
(95 %RH at 30 °C)
Storage and transportation
humidity
5-100 % RH, condensing
O
peration atmospheric
pressure
525-1200 hPa (525hPa corresponding to an altitude of 4572 m/1500
0
feet)
S
torage and transportation
pressure
500 to1200 hPa
Total system response time ＜1 second
Accuracy specifications(during
standard conditions）
Range Accuracy
0 to 114 mmHg ±(0.2 mmHg + 2% of reading)
High Continues Pressure
It will give an alarm when the airway pressure is
continuous above
（PEEP+15）cmH
2
O for 15 seconds
Apnea Range:10～60 s, increment :5 s
O
2
supply pressure low The O
2
supply pressue is less than 0.28 MPa
Air supply pressure low The O
2
supply pressue is less than 0.28 MPa
AC failure The alarm time is more than 120s
Low battery capacity The battery working time is 10 minutes after alarm
Battery exhausted The battery working time is 5 minutes after alarm
Alarm silence count down ≤100 s
Alarm sound >65dB
