D.2 Equipment symbols
Consult inst
ructions for
use
Alarm silence icon
Manual inspiration button Inspiration hold button
Expiration hold button Alarm silence button
100% O
2
2 minutes button Alarm reset button
Lock button Standby button
E
xpiration valve unlock
label
AC power indicator
light
Battery indicator light Battery
Nebulizer
Screen and
membrane button lock
Screen and membrane
button unlock
Inspiration port
Expiration port
CE mark
Vendor -
special data
serial port
Fuse
The air source connector
The Oxygen source
connector
RS 232
Serial port
Vendor - special data port
System switch
Manufacturer
Year of manufacture
Serial number
Authorized
representative in the
EUROPEAN
COMMUNITY
