GEM5000 Gas Analyzer
Page 80 of 102
10.7.8 Sending ID’s to the Instrument
Once IDs have been created in the project, they must be uploaded to the instrument. To
perform this operation, select the desired IDs from the left hand table under the Project
name (computer side), left click and hold while dragging the IDs to the right hand table and
release the mouse button. This is action is known as a “Drag & Drop”.
Three basic methods of selecting IDs exist.
Select Specific ID(s)
Select a Range of IDs
Select All IDs
Specific IDs
To Select Specific IDs from the List, place the mouse arrow at the edge of the first cell
and hold down the left Ctrl key. Now click the next ID cell that you wish to select. Repeat this
as many times as necessary.
Selected IDs (shown as Highlighted). Arrow depicts "Drag & Drop" action after selection.
Now “Drag & Drop” the IDs from the left (computer window) to the right (instrument
window). During the “Drag &Drop” process, the arrow will change to .
The selected IDs ALFP001, ALFMW002, and ALFMW004 now appear on the Right (Instrument)
side. At this point the IDs are on the Instrument side but have NOT been sent to the
instrument. The instrument with the red asterisk * indicates this unsent ID state.
Click on the Send to Instrument button to send these IDs to the instrument.
