Quantum Data 980 DP User Manual

980 DP Video Generator - User Guide Rev. A4
Page 150 July 14, 2014
Field
Type
Description / Function
 IEC 60958-3 Consumer LPCM.
 IEC 60958-4 Professional LPCM.
 IEC 61937 w/AC-3 (Dolby Digital).
 MP2 (Video CD) (not used).
 MP3 (MPEG1 Layer 3) (not used).
 MPEG2 5.1 channels Advanced Audio Coding (AAC)
 MPEG2 7.1 channel CBR or VBR
 IEC 61937 w/’DTS

ATRAC
Level Shift
Entry field
Sets the digital audio level shift value for linear PCM. The valid values
are: 0 - 15 dBFS.
Parameter is: DALS
Sampling Rate
Entry field
Sets the digital audio sampling rate for linear PCM. The valid values
are:
 32.0kHz
 44.1kHz
 48.0kHz
 88.2kHz
 96.0kHz
 176.4kHz
 192.0kHz
Parameter is: ARAT
Number of Streams
Entry field
Sets the digital audio streams. The valid value is: 1.
Parameter is: NDAS.
Number of Channels
Entry field
Sets the digital audio sampling rate for linear PCM. The valid values
are: 2 through 8
Parameter is: NDAC.
Bits per Sample
Pull-down select
Sets the digital audio sampling rate for linear PCM. The valid values are:
 16
 20
 24
Parameter is: NBPA.
Contents Gated
Entry field
Sets the digital audio content gate. The valid values are:
0 through 4095. Refer to EIA/CEA-861-x.
Contents Available
Entry field
Sets the digital audio content available. The valid values are: 0
through 4095. Refer to EIA/CEA-861-x.
Mix Down Gate
Check box
Sets the digital audio down-mix gate. The valid values are: enabled (0)
