Quantum Data 980 DP - Acer7 and Acer8

980 DP Video Generator - User Guide Rev. A4
Page 195 July 14, 2014
11.6 Acer7 and Acer8
11.6.1 Description
Special test image developed per customer specifications. In the primary version, five blocks of either white “#”
(Acer7) or “H” (Acer8) characters on a black background are displayed. A secondary version displays black
characters on a white background. The Acer7 image is shown below.
