980 DP Video Generator - User Guide Rev. A4

Page 202 July 14, 2014

11.13 Audio_L, Audio_Lf, Audio_R, Audio_Rf, Audio_X, Audio_Xf

11.13.1Description

Used to configure HDMI audio output signal. The Audio_L is shown below. For more information, see “Testing

HDMI audio” on page 305.
