7.5 New Format - Digital Audio Tab
The Format Editor Digital Audio tab is shown below. The table that follows describes each of the fields in the tab.
The table below describes each of the fields in the Digital Audio tab.
Field
Type
Description / Function
Signal Interface
Not used for DP
Pull-down select
Sets the digital audio signal interface. The valid values are:
 None - Use DP.
 SPDIF.
 AES3 (not used).
 AESid (not used).
 TOSlink optical (not used).
 MiniPlug (not used).
Signal Type
Pull-down select
Sets the digital audio signal interface. The valid values are:
 None
