allowing you to change its value.
• Upon modifying a format value hit the enter key to invoke the change. The Format Editor applies the new
value to the timing algorithm and updates any values dependent on the value you entered (or changed).
For example, to change the horizontal resolution to 660, enter the value in the
Active field under Pixels in the Horizontal area.
You will notice that the Format Editor has calculated and written values to the Blank and Period fields as
indicated by the red calculator
(
) symbol. Although the Period value has not changed, the Format
Editor still indicates it is a calculated value by displaying the red calculator.
• To apply the format settings on the generator, click the Use activation button on the lower right side.
8. Use (apply) the modified format by clicking on the Use activation button on the bottom of window.
Monitor the display under test for roper operation.
